P a g e | 143

GWN7000 User Manual

Version 1.0.6.28

Figure 90: Syslog

Connection Table

NAT table is updated dynamically on GWN7000’s WebGUI, to check the NAT table go to System

Settings→Debug→Connection Table.

Users could press button to clear all entries.
