P a g e | 19

GWN7000 User Manual

Version 1.0.6.28

INSTALLATION

Before deploying and configuring the GWN7000, the device needs to be properly powered up and

connected to the network. This section describes detailed information on installation, connection and

warranty policy of the GWN7000.

Equipment Packaging

Table 2: GWN7000 Equipment Packaging

Main Case

Yes (1)

Power adaptor

Yes (1)

Quick Installation Guide

Yes (1)

GPL License

Yes (1)

Connect your GWN7000

Figure 1: GWN7000 Front View
