Management

• Web, CLI

Power

• 802.3at PoE (To power the unit via LAN1 port)

• Included Power Supply: 12V/2A

• Max power consumption: 16W

Environmental

• Operation: 0°C to 50°C

• Storage: -10°C to 60°C

• Humidity: 10% to 90% Non-condensing

Physical

• Unit Dimensions: 200 x 136 x 37mm; Unit Weight: 570g

• Entire Package Dimensions: 324 x 163.5 x 54mm, Entire Package

Weight: 930g

Package Content

• GWN7000 Enterprise Router

• 12V/2A Power Adapter

• Quick Installation Guide

• GPL License

Compliance

• FCC, CE, RCM, IC
