P a g e | 78

GWN7000 User Manual

Version 1.0.6.28

Figure 50: Generate Server Certificates

Table 26: Server Certificate

Field

Description

Common Name

Enter the common name for the server certificate.

It could be any name to identify this certificate.

Example: “ServerCertificate”.

CA Certificate

Select CA certificate previously generated from the drop-down list.

Example: “CATest”.
