GWN7000 User Manual
Version 1.0.6.28
IP Family
Select the IP version, three options are available: IPv4, IPv6 or Any.
Source Group
Select a WAN interface or a LAN group for Source Group, or select All.
Destination Group
Select a WAN interface or a LAN group for Destination Group, or select
All. Make sure that destination and source groups are different to avoid
conflict.
Protocol
Select one of the protocols from dropdown list or All, available options
are: UDP, TCP, TCP/UCP and All.
Source IP
Set the Source IP address.
Rewrite IP
Set the Rewrite IP. The source IP address of the data package from the
source group will be updated to this configured IP.
Destination IP
Set the Destination IP address.
Schedule Start Date
Click on icon to schedule a start date for this SNAT entry to be
applied.
Schedule End Date
Click on icon to schedule an end date for this SNAT entry to end.
Schedule Start Time
Click on icon to schedule a start time for this SNAT entry to be
applied.
Schedule End Time
Click on icon to schedule an end time for this SNAT entry to end.
Schedule Weekdays List of
Weekdays
Select the days, on which the SNAT entry will be applied, the unselected
days will ignore this rule.
Schedule Days of the Month
Enter the days of the months (separated by space) on which the SNAT
entry will be applied.
Example: 5 10 15
This will be applied only on 5
th
, 10
th
and 15
th
day monthly.
Treat Time Values as UTC
Instead of Local Time
Check to use UTC as time zone for the specified times, instead of using
GWN7000’s local time.
DNAT
Following actions are available for DNAT:
• To add new DNAT entry, click on
• To edit a DNAT entry, click on
• To delete a DNAT rule, click on
