GWN7000 User Manual
Version 1.0.6.28
6rd IPv4 Peer
Address
Enter the IPv4 Peer address.
6rd IPv6 Address
Prefix
Specifies the IPv6 prefix given by the provider.
Example: 2001:B000::/32
IPv6 Prefix Length
Specifies the IPv6 prefix length (Value between 1 and 128).
Example: 32
IPv4 Prefix Length
Specifies the prefix length of the IPv4 transport address.
(Value between 1 and 32).
Table 9: AICCU Tunnels
WAN Interface
Choose the WAN port on which to setup the aiccu tunnel.
Username
Enter the Username (Provided by signing up with SixXS Tunnel Broker)
Password
Enter the Username’s password
Table 10: GRE Tunnels
WAN Interface
Specifies the WAN interface to bind the tunnel to.
Name
Set a name for the tunnel connection.
Enabled
Enabled/Disable the tunnel connection.
GRE Peer IP Address
Specifies the tunnel destination address (public IP).
GRE Tunnel IP
Address
Specify the local GRE tunnel interface. (ex: 10.1.1.2)
GRE Tunnel Netmask
Set the Tunnel interface netmask. (ex: 255.255.255.0)
MTU
Configures the maximum transmission unit. The valid range is 64-9000 and the
default is 1500.
Subnet
Set the destination subnet that is reachable though GRE tunnel.
IP Masquerading
Enable/Disable IP masquerading. Users could configure this option under the
“General” tab of Firewall → Advanced as well.
Tunnel Input Key
Specifies the key that would be added to the incoming packets.
Tunnel Output Key
Specifies the key that would be added to the outgoing packets.
