GWN7000 User Manual
Version 1.0.6.28
Check to enable VLAN. This field is appearing only when having more than
one LAN subnet.
Set a VLAN ID. Valid range is between 2 and 4093.
Check to enable IPv4 addressing for this LAN.
Set a static Ipv4 address for the LAN subnet when enabling Ipv4.
Additional IPv4 Static
Address
Set an additional static Ipv4 address for the LAN subnet when enabling
IPv4.
Check to enable DHCP using Ipv4. This will allow clients connected to this
LAN subnet to get Ipv4 addresses automatically from GWN7000 acting as
DHCP server.
Set the starting Ipv4 address for this LAN’s clients.
Set the ending Ipv4 address for this LAN’s clients
Set the lease time for DHCP clients, the value can be defined in hours,
minutes, or as “infinite”. Default lease time is “12h”.
Set the DHCP options. Click on to add another option, and to
delete an option.
Example: 44,192.168.2.50 for DHCP option 44 and 192.168.2.50 is the
WINS server’s address. Please refer to the following link for DHCP options
syntax: https://wiki.openwrt.org/doc/howto/dhcp.dnsmasq
Defines the IP address of the DHCP gateway.
Set the preferred DNS Servers via DHCP.
Set the alternate DNS Servers via DHCP.
Enable this option, if you want the GWN7000 relays the DHCP requests
from clients to another DHCP server(s). Once checked, click to add
another DHCPv4 Relay Target, and to delete a DHCPv4 Relay Target.
Check to enable IPv6 addressing for this LAN subnet.
Check to allow GWN7000 to relay IPv6 DHCP request from LAN’s clients
to WAN port.
Check weather to enable IPv6 DHCP server for this LAN.
IPv6 Prefix for Assignment
Set the prefix value to be assigned to the LAN. Valid range is between 1
to 64. Example: 64 will assign /64 prefixes.
Set the subnet mask value.
