액세스 덮개 분리
배선 단자에 연결하려면 액세스 덮개를 분리합니다. 그림 11 참조하십시오.
그림 11 액세스 덮개 분리
배선 연결 개요
그림 12 에서는 가능한 모든 배선 연결을 보여 줍니다. 해당 연결에 대해 지정된 와이어 게이지를 사용
하십시오(사양 148 페이지의 참조).
140
한글

Table of Contents

Other manuals for Hach 5500sc SiO2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hach 5500sc SiO2 and is the answer not in the manual?

Hach 5500sc SiO2 Specifications

General IconGeneral
Power Requirements100 - 240 VAC, 50/60 Hz
Resolution0.001 mg/L
Light SourceLED
DetectorPhotodiode
Sample Flow Rate200 to 500 mL/min
Operating Temperature5 to 45 °C
Sample Temperature5 to 45 °C
Outputs4-20 mA
EnclosureNEMA 4X/IP66
MethodHeteropoly blue method
