Remote PHY DOCSIS node
Figure 2-1: Ripple-2 node platform
Number Component Description
- Base
Connected physically to the lid by a hinge, and electrically with
RF jumper cables, AC power cable and DC power and control
cables.
Components:
• Configurable Hybrid Bias 2x4 RF tray
• Two AC buses
• Four RF ports
• Forward and return path RF circuitry
• Pluggable diplexer filters
• Replaceable SIDACtor board
13 Installation Guide
