Hardware shipping bundles
Number Component Description
DC (+ control)
Cable Connector
Connectors for connecting DC power (and control cables)
between the base and lid.
17 DC Cable Connects DC power (and control cables) between the base
and lid.
18 Buoy Power
Backup module
(optional)
Buoy allows the node to withstand brief power interruptions
(up to 4 seconds in duration), with minimal disruption to
service. The Buoy Power Backup module fits into the 2nd PSU
compartment of the node, and is hot-swappable.
19 Jetty-1 module
Remote Switch
20 SFP ports 6 SFP Ports. Can be populated with SFP+ compliant
packages containing:
• 6x Ethernet
• 1x Ethernet + 5x Fin-1 Remote OLT
• 2x Ethernet + 4x Fin-1 Remote OLT
◦ I-Temp: N0 / PR10+, 1:16 @20km, 1:64 maximum
21 Optical fiber port Two optical fiber ports are available.
Related information
RF tray segmentation and configuration options
Hardware shipping bundles
Ripple-2 node platforms are shipped as two types of bundles depending on their intended deployment.
Bundles
Bundles include a selection of several pre-installed components grouped under a single Product Part
Number:
• Remote PHY DOCSIS and DOCSIS / FTTx Hybrid node platform bundles includes:
◦ Node housing, including fiber manangement tray
◦ Power supply selection
◦ RF tray
• Remote FTTX Switch platform bundle includes:
◦ Node housing, including fiber manangement tray
◦ Power supply selection
◦ Tamper switch
Standalone components are shipped separately and include:
• Pebble-2 RPD or RMD
• Jetty-1 Switch(es)
25 Installation Guide
