Viewing Ripple-2 Node configuration with Show commands
Parameter Description
FORWARD SEG Forward path segmentation:
◦ rpd1 = Pebble-2 in slot 1
◦ l = left side of Ripple node for RF ports P1, P2
AGC PWR DETECT
◦ 0 = no AC power to Ripple node
◦ 1 = AC power being supplied to Ripple node
HYBRID
◦ True = Hybrid ports P2 and P4 are on
◦ False = Hybrid port P2 and P4 are shut off
PORT The RF port::
◦ 1 = P1
◦ 2 = P2
◦ 3 = P3
◦ 4 = P4
RETURN SEG Return path segmentation:
◦ rpd1 = Pebble-2 in slot 1
◦ us1 = US path through Pebble-2 US1 port
RETURN ATTN Return path attenuation setting
• Show the current node lid status: admin@CableOS> show rpn <rpn-id> lid
Parameter Description
<rpn-id> Ripple node ID:
◦ <ddd.ddd.ddd.ddd> = Selects RPD by dotted decimal IPv4 address
◦ <hhhh.hhhh.hhhh> = Selects RPD by 48-bit MAC address
◦ rpd-vcvs-addr [CC:SS] = Virtual slot
For example: admin@CableOS> show rpn 1:0 lid
Tamper Sensor: Closed
Temperature: 36.0C/96.8F
Non-volatile Database: Valid
Parameter Description
Tamper Sensor The Ripple node is equipped with a tamper sensor that indicates if the lid is
closed or has been left open
Temperature The current operating temperature within the Ripple node
Non-volatile
Database
Indicates if the database is online or offline
• Show the current node power status: admin@CableOS> show rpn <rpn-id> power
Parameter Description
<rpn-id> Ripple node ID:
65 Installation Guide
