Chapter 5: Configuring the Ripple-2 Node
Parameter Description
◦ <ddd.ddd.ddd.ddd> = Selects RPD by dotted decimal IPv4 address
◦ <hhhh.hhhh.hhhh> = Selects RPD by 48-bit MAC address
◦ rpd-vcvs-addr [CC:SS] = Virtual slot
For example: admin@CableOS> show rpn 1:0 power
GENERAL
PS NO. AC INPUT (VAC) +5 (VDC) DC SELECT (VDC) +24/34 VDC TEMPERATURE
------ -------------- -------- --------------- ---------- -----------
0 72.0 +5.0 +1 +34.0 46.0C/115F
ELECTROLYTIC ELECTROLYTIC
CAPACITOR 1 TEMP CAPACITOR 2 TEMP
---------------- ----------------
48.0C/118F 49.0C/120F
Parameter Description
PS NO. Power supply ID:
◦ 0 = power supply on left side of Pebble-2 slot 1
AC INPUT (VAC) Actual AC input voltage to Ripple node from designated PS NO.
+5 (VDC) The 5V rail on the Ripple power supply from designated PS NO.
DC SELECT (VDC) The DC Select switch on the power supply:
◦ +1 = 34V setting
◦ 0 = 24V setting
+24/34 VDC Connected to DC SELECT setting, displays the DC voltage of the selected
rail
GENERAL
TEMPERATURE
Current operating temperature of designated PS NO.
ELECTROLYTIC
CAPACITOR 1 TEMP
For future use: Internal temperature of capacitor 1 of this (PS NO.) power
supply
ELECTROLYTIC
CAPACITOR 2 TEMP
For future use: Internal temperature of capacitor 2 of this (PS NO.) power
supply
• Combine the lid and power commands in one output: admin@CableOS> show rpn <rpn-id>
verbose
Parameter Description
<rpn-id> Ripple node ID:
◦ <ddd.ddd.ddd.ddd> = Selects RPD by dotted decimal IPv4 address
◦ <hhhh.hhhh.hhhh> = Selects RPD by 48-bit MAC address
