Ellipse Set-Up Procedures
13. In the VBI menu select Teletext Subtitling.
14. Use the Teletext Initial Page option to set the page number to 100 (use the alphanumeric
touch-pad to page number).
15. Press <Enter> to confirm and return to the Teletext Subtitling menu.
16. Use the Teletext Initial Language option to set the language.
17. Press <Enter> to confirm and return to the Teletext Subtitling menu.
18. Select Activation to enable the teletext subtitling activation.
19. Press <ESC>, and <ESC> a second time to return to the VBI menu.
20. Press F1 on the front panel to save the new service (refer to Section 2.1.1.3. for configuration
save instructions).
2.2.3.2 MPEG-2 Analog Video Configuration Set-up Procedure
This procedure uses the front panel interface. It can be equally performed using the web manager
interface. Refer to section 5.1.2 Analog Interface Sub-Menu/box of this manual for detailed
information about the options provided on each front panel and the respective web manager
interface.
All parameters not set in the procedure should be set to their default values (video resolution set
to automatic; channel maximum rate at 4.5 Mbps and latency control at normal).
To define an MPEG-2 coding profile for an SD PAL analog video program received on the CV
analog input for an elementary stream with PID 450:
1. Navigate Root > Configuration > Video > Video > Input > Physical Input.
2. Configure Physical Input to CV.
3. Press <Enter> to confirm and return to the Input menu.
Teletext Subtitling
01 Activation
Disabled
02 Teletext Initial Page
700
03 Teletext Initial Page Language
spa
04 Teletext Page 0
777
Input
1 Video Source
Video Input
2 Physical Input
CV
3 Input Format
PAL
4 Output on Video Loss
Color Bars
5 Sync Mode
Internal Clock
