10/6/10 888-2629-200 2-61
WARNING: Disconnect primary power prior to servicing.
Section 2 Installation
Maxiva ULX COFDM Series
J7-9 VSWR FAULT L=FAULT
H= OK
J7-10 TRANSMITTER_FAULTED_OFF L= FAULT OFF
H= OK
J7-11 GROUND
J7-12 GROUND
J8-1 GROUND
J8-2 EXCITER_FAULT L=FAULT
H= OK
J8-3 PA_FAULT L=FAULT
H= OK
J8-4 IPA_FAULT L=FAULT
H= OK
J8-5 GROUND
J8-6 COOLING_FAULTt L=FAULT
H= OK
J8-7 POWER_SUPPLY_FAULT L=FAULT
H= OK
J8-8 GROUND
J8-9 SUMMARY_FAULT L=FAULT
H= OK
J8-10 CUSTOMER_SUPPLIED_VCC1 ( voltage for digital
output opto-couplers and pull-ups)
JP1 in the TCU customer I/O
card must be set correctly to
use this output.
J8-11 CUSTOMER_SUPPLIED_VCC2 (voltage for digital
output opto-couplers and pull-ups)
JP1 in the TCU customer I/O
card must be set correctly to
use this output.
J8-12 GROUND
Table 2-13 J6, J7 & J8 Customer I/O Board, Remote Status Outputs
Connector
and pin #
Status Output Status Type and Polarity
