10/6/10 888-2629-200 7-1
WARNING: Disconnect primary power prior to servicing.
Maxiva ULX COFDM Series
Section 7
Parts List
7
7.1 Replaceable Parts List
Table 7-1 MAXIVA 16PA FORMAT TRANSMITTER - - - - - - 9950228001G (P) 7-2
Table 7-2 SYS, CLOSED LP CLING; 3 FAN, 208/240VAC, 50HZ 708 0088 001 (A) 7-3
Table 7-3 SYS, CLOSED LP CLING; 3 FAN, 208/240VAC, 60HZ 708 0088 002 (A) 7-3
Table 7-4 SYS, CLOSED LP CLING; 3 FAN, 380/415VAC, 50HZ 708 0088 003 (A) 7-3
Table 7-5 SYS, CLOSED LP CLING; 3 FAN, 380VAC, 60HZ - - 708 0088 004 (A) 7-3
Table 7-6 CABLE, ANALOG EXCITER B I/O- - - - - - - - - - 952 9253 058 (A) 7-3
Table 7-7 *ASSEMBLY, TRITON PA MODULE - - - - - - - - 971 0040 003 (B) 7-3
Table 7-8 ASSEMBLY, PA MODULE, BASIC, TRITON - - - 971 0040 100 (E) 7-3
Table 7-9 ASSEMBLY, MAXIVA ULX PA MODULE- - - - - - 971 0040 004 (P) 7-4
Table 7-10 DUAL CIRCUIT BREAKER ASSEMBLY, 208-240V - 971 0040 033 (J) 7-4
Table 7-11 ANALOG PKG 16PA- - - - - - - - - - - - - - - - - 971 0040 059 (B) 7-5
Table 7-12 CABLE ,ANALOG EXCITER A I/O - - - - - - - - - 952 9253 057 (A) 7-5
Table 7-13 CABLE ANALOG RF - - - - - - - - - - - - - - - - 952 9253 063 (C) 7-5
Table 7-14 CUSTOMER I/O ASSEMBLY, ANALOG - - - - - - 971 0040 022 (D) 7-5
Table 7-15 MAXIVA 16PA BASIC TRANSMITTER - - - - - - - 981 0418 001 (AB) 7-6
Table 7-16 ASM, TOP, UCP-TRITON SYSTEM-16PA- - - - - - 981 0293 002 (F) 7-7
Table 7-17 MAXIVA COMMON COMPONENTS- - - - - - - - 981 0400 001 (AD) 7-8
Table 7-18 FAN ASSEMBLY, MAXIVA ULX - - - - - - - - - 971 0040 025 (F) 7-9
Table 7-19 PRE DRIVER UNIT, MAXIVA ULX - - - - - - - - 971 0040 030 (K) 7-10
Table 7-20 PRE DRIVER TRAY, MAXIVA ULX - - - - - - - 971 0040 031 (K) 7-10
Table 7-21 DP, MAXIVA ULX - DIGITAL, 1 CAB XMTR - - - - 988 2627 001 (B) 7-11
For table above and in tables that follow in this section the (X) or (XX) after the table title part
number is the revision level of that bill of material and is for reference only.
