Harris Maxiva ULX User Manual

7-2 888-2629-200 10/6/10
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Maxiva ULX COFDM Series
Table 7-1 MAXIVA 16PA FORMAT TRANSMITTER - 9950228001G (T P)
Harris PN Description Qty UM Reference Designators
472 1888 000 "XFMR, 480V/208V, 3 PH, 112.5 KVA, K13 RATED"0 EA
708 0090 010 "PUMP MODULE, 380/415 VAC 50HZ" 0 EA
708 0090 011 "PUMP MODULE, 380/415 VAC 60HZ" 0 EA
708 0090 012 "PUMP MODULE, 208/240 VAC 50 HZ" 0 EA
708 0090 013 "PUMP MODULE, 208/240 VAC 60 HZ" 0 EA
708 0090 014 "50KW HEAT EXCHANGER, 380/415V 50HZ"0 EA
708 0090 015 "50KW HEAT EXCHANGER, 380/415V 60HZ"0 EA
708 0090 016 "50KW HEAT EXCHANGER, 208/240V 50HZ"0 EA
708 0090 017 "50KW HEAT EXCHANGER, 208/240V 60HZ"0 EA
774 0156 058 "KIT, COOLANT CHARGE PUMP" 0 EA
774 0156 080 "KIT, PLUMBING ULX/VLX 1PA HOSE" 0 EA
774 0156 081 "KIT, PLUMBING ULX/VLX 1PA PIPE" 0 EA
943 5276 184 MAXIVA ULX SYSTEM WIRING KIT 0 EA
952 9253 017 CABLE JUMPER PLUG 208-240V 0 EA
952 9253 018 CABLE JUMPER PLUG 380-415V 0 EA
952 9253 019 CABLE EXC A ASI 0 EA
952 9253 020 CABLE EXC B ASI 0 EA
952 9253 021 CABLE EXC A RF EXTERNAL 0 EA
952 9253 022 CABLE ECX B RF EXTERNAL 0 EA
952 9253 058 "CABLE, ANALOG EXCITER B I/O" 0 EA
971 0040 003 "*ASSEMBLY, TRITON PA MODULE" 0 EA
971 0040 004 "ASSEMBLY, MAXIVA ULX PA MODULE" 18 EA
971 0040 020 "CUSTOMER I/O ASSEMBLY, DIGITAL" 0 EA A1
971 0040 033 "DUAL CIRCUIT BREAKER ASSEMBLY, 208-240V"0 EA
971 0040 037 "DUAL CIRCUIT BREAKER ASSEMBLY, 380-415V"0 EA
971 0040 059 ANALOG PKG 16PA 0 EA
971 0040 075 "KIT, CE DIGITAL MAXIVA ULX" 0 EA
971 0040 080 "UNIT, PA DIAGNOSTICS" 0 EA
971 0040 095 "KIT, SINGLE EXCITER" 0 EA
981 0222 012 "MAXIVA ULX, PA MODULE TEST FIXTURE"0 EA
981 0418 001 MAXIVA 16PA BASIC TRANSMITTER 1 EA
988 2627 200 "DP, MAXIVA ULX-ATSC, 1 CABINET" 0 EA
988 2628 200 "DP, MAXIVA ULX-ANALOG, 1 CABINET" 0 EA
988 2629 200 "DP, MAXIVA ULX-COFDM, 1 CABINET" 0 EA
992 9139 090 "KIT, INSTALL MATERIAL, MAXIVA 1 PA CAB"0 EA
995 0063 001 "FORMAT, EXCITER, APEX M2X (DVB-T/H)"0 EA "A2,A3"
995 0063 002 "FORMAT, EXCITER, APEX M2X (ISDB-T)" 0 EA "A2,A3"
995 0063 005 "FORMAT, EXCITER, APEX M2X (ATV)" 0 EA "A2,A3"
995 0063 200 "EXCITER, APEX M2X (ATSC)" 0 EA "A2,A3"
484 0606 000 "FILTER, LOW PASS, UHF, BAND A" 0 EA
484 0607 000 "FILTER, LOW PASS, UHF, BAND B" 0 EA
484 0608 000 "FILTER, LOW PASS, UHF, BAND C" 0 EA
484 0781 000 "FILTER, LOW PASS, UHF, 4-1/16'' BAND A" 0 EA
484 0782 000 "FILTER, LOW PASS, UHF, 4-1/16'' BAND B" 0 EA
484 0783 000 "FILTER, LOW PASS, UHF, 4-1/16'' BAND C" 0 EA
484 0784 000 "FILTER, LOW PASS, UHF, 4-1/16'' BAND D" 0 EA
981 0202 001 "FILTER, LOW PASS DTV IN-SYSTEM" 0 EA
981 0202 002 "FILTER, LOW PASS DTV IN-SYSTEM" 0 EA
981 0202 003 "FILTER, LOW PASS DTV IN-SYSTEM" 0 EA
