WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Maxiva ULX COFDM Series
7.2 Heat Exchanger/Pump Module Replacement Parts
Table 7-21 Spart Parts for Pump Module & Heat Exchager
DCI Part
Number
Part Description
14780 Replacment Motor Assembly, 19.7" diameter - Harris PN 7080061001 This fan is used for air
cooler Harris PN: 7080060008, 7080060006, 7080060010
14782 Replacement Motor Assembly, 19.7” DIA This fan is used for 50kW Harrris PN:7080090015,
7080090017
11965 1-1/2" NPT Check Valve
1478 Gauge Cock 1/4" NPTFXNPTM MiniI Brass Ball Valve w/ T-Handle, 300 PSI rating , max
Temp 212F, teflon seat and Viton seals
15194 0.25” Blow-Down Valve with 3/4” garden hose male cap and retainer
2301 1/2" Brass Ball Valve, NPT, full port, two piece, UL, FM, & CSA approved, 150 WSP, chrome
plated brass ball, PTFE seats, seals and thrust washer, BUNA o-rings
2311 1 1/2" Brass Ball Valve, NPT, full port, two piece, UL, FM, & CSA approved, 150WSP, chrome
plated brass ball, PTFE seats, seals
9303 Type "J" MGO Thermocouple with jack, 0.250 OD X 4" long, 304SS sheath, ungrounded
junction, 1/4" NPTM brass compression FTG, STD male
6419 Ft of Type "J" Thermocouple Extension Wire 20Ga red / white with solid duplex-parallel
extruded PVC jacket insulation, 221F insulation
14862 1.25” Terminator Ball Valve union end No PT, C x M, copper X male NPT
14861 1.5” Terminator Ball Calve union end NO PT, F x F, NPT
12810 1.5 Ball Valve with strainner, pressure ports and union, FPT X FPT union with 3/4" bypass port,
1/4" strainer drain port, brass (#15)
9638 0.75" B&G AIR VENT NO 87, brass, non-ferrous automatic air vent
2062 0.5" Fast Fill Dual Pressure Relief / Presssure Reducing Valve, FNPT, brass, max pressure 10
PSI, adjustment range 10 TO 25 PSI
14716 1.5" Bell & Gossetti In Line Air Scoop, 3/4" NPT top vent, 1/2" bottom tank connection overall
length 8.125", max flow 35 GPM, max op.
12429 0002 Gallon, Diaphragm Expansion Tank, 1 gallon acceptance volume, 12 PSI pre-charge, 0.5"
system connection, max op. temp 240F, max
14845 Motor Pump 126, 2HP, 1.25”X1.25”, TEFC, 60Hz, 380-400V/3/60 or 230-460/3/60, 3500
RPM, J56, Standard Fitted, BN-CM Seal, 5.25” Impeller Diameter, 35 gpm @ 35 psi
