WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Maxiva ULX COFDM Series
1595 Pressure Gauge, 0-100 PSI, 2.5", LF, 1/4" brass NPTM, bottom MNT,glycerin filled, bronze
tube, brass socket, acrylic window S.S. case
15134 Brass Garden Hose-to-Pipe Rigid Adapter 3/4" Male Garden Hose, 1/2" NPT male connections
11965 1-1/2" NPT Check Valve
15133 Replacement Filter for 1.5” Ball Valve with Strainer, 304SS with 20-mesh screen
12957
CONTROL PANEL
8028 ABB Non-Fused Disconnect Switch, 30A 600V-3P, UL98
3785 ABB Disc. Shaft, 180mm (w/3786 & 11212 SH 30-100A)
11212 ABB Disconnect Selector Handle, 30-100A, Red/Yellow
14856 ABB Door mounted, Non-Fused Disconnect Switch, 30A 600V-3P, UL508
14857 ABB Selector Handle for UL508 Door Mounted Disconnect (OT16,25,32ET3), Black, UL/
NEMA type 1/3R/12, IP65
14855 Transformer, 150VA
13841 Fuse Holder & Cover Kit for Sola XFMR
6603 Fuse, 2A-600V, Class CC Time Delay Rejection Type
2197 Fuse, 3.2A-600V, Class CC Time Delay Rejection Type
14726 Power Supply, 15W/12VDC/1.2A Output
14850 Socket Base for ABB Alternating Relay, 11-Pin
14848 Alternating Relay, 120VAC, DPDT, with rotary switch, 11-pin octal base.
14849 Hold Down Clips for ABB Alternating Relay (DPDT, 11 pin)
14322 Circuit Breaker, 2A-1P, 480Y/277V, UL1077, D curve.
14315 Circuit Breaker, 0.5A-1P, 480Y/277V, UL489, D curve.
12957 IDEC Relay Socket, Finger Safe, for GT5Y Timer, and 4PDT relay, screw connections
11024 IDEC Relay, 4PDT, 12 VDC
15009 Cutler-Hammer, MMP, 4.0-6.3A, frame-B, rotary operator, class 10 overload protection
15032 Cutler-Hammer, MMP, 2.5-4.0A, frame-B, rotary operator, class 10 overload protection
Table 7-21 Spart Parts for Pump Module & Heat Exchager
DCI Part
Number
Part Description
To Next Page
