10/6/10 888-2629-200 7-15
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Maxiva ULX COFDM Series
15008 Cutler-Hammer, MMP, 1.6-2.5A, frame-B, rotary operator, class 10 overload protection
15014 Cutler-Hammer, MMP Plug Connection Kit, frame-B
15011 Cutler-Hammer, MMP Auxiliary Contact, 1NO-1NC, front mount, 1NO-1NC, seq-A, use with
XT series MMPs
10837 Cutler-Hammer Contactor,7A,3P, 120VAC Coil, 1NO aux contact
11027 Cutler-Hammer Aux-Contact, 2 NO-2 NC,front mount, frame B-C
15013 Cutler-Hammer, MMP Line Side Adapter, frame B
15012 Cutler-Hammer, MMP 3-Ph Bussbar, 4-MMP commoning link-B, frame-B
9300 IDEC Momentary Pushbutton, 1NC Contact, black flush type
14825 IDEC Selector Switch, 2-Position, 1NC contact
7902 IDEC Contact Block, 1NC
7883 IDEC Pilot Light, Green LED, 120VAC round flush type
10535 Cage Clamp Term. Block RED/2L
10538 Cage Clamp Term. Block WHITE/2L
10536 Cage Clamp Term. Block BLUE/2L
14779 Cage Clamp Term. Block ORANGE/2L
10543 Cage Clamp End Plate GREY/2L
10539 Cage Clamp Term.Block(GRND) Green/Yellow/4L
10561 Cage Clamp End Plate GREY/4L
10545 Cage Clamp Term.Block End Stop
14852 Tempco TEC-9300 Temperature Controller, 90-264 Vac, 1/16DIN, Universal Input, NEMA-4X/
IP65 Front Panel.
Output-1: Relay
Output-2: Relay
Alarm-1: Relay
Model TEC-9300-411110
Table 7-21 Spart Parts for Pump Module & Heat Exchager
DCI Part
Number
Part Description
