WARNING: Disconnect primary power prior to servicing.
Section 1 Introduction
Maxiva ULX COFDM Series
more than 5 seconds in an active pump will cause activation of the standby pump. Loss
of flow for more than 15 seconds will cause both pumps to shut down.
1.2.8.3 PA Module and Combiner Cold Plates
Each PA Module has a liquid cooled cold plate which connects to the cooling system
with quick release connectors. There are also cold plates inside the combiner and the
splitter to which all of the internal combiner reject loads are attached. See
Figure 1-12
for cabinet coolant routing and module slot numbering.
NOTE:
The module slot numbering should not be confused with the IPA and PA module
numbering. Module numbering and slot locations will vary depending on model
number. See the outline drawing to identify which PA modules go in which slot
locations dependent on model.
