10/6/10 888-2629-200 3-1
WARNING: Disconnect primary power prior to servicing.
Maxiva ULX COFDM Series
Section 3
Operation
3
3.1 Introduction
This section gives detailed operational information for the Maxiva ULX Series Solid-
State UHF TV transmitter. Information will pertain mostly to the operation and
navigation of the TCU graphical user interface (GUI) touchscreen display.
NOTE:
Operation of the M2X exciter is covered in a separate manuals which ships with
the transmitter.
3.2 Transmitter Control Panel
The front panel user interface is a 5.25" 1/4 VGA, LCD touchscreen display. This
touchscreen display uses software buttons to monitor the transmitter. Hardware buttons
for the primary transmitter functions such as ON/OFF, RAISE/LOWER and Remote
Enable/Disable are provided on the overlay panel next to the display as shown in
Figure
3-1.
NOTE:
When transmitter is turned off using the OFF button under normal conditions, the
pump module pump will continue to operate for several minutes before shutting
down. If immediate pump shutdown is desired then pump module can be turned
off at the control panel.
