2-2 888-2629-200 10/6/10
WARNING: Disconnect primary power prior to servicing.
Section 2 Installation
Maxiva ULX COFDM Series
The following is a list of documentation that ships with the transmitter. Find and save
all documentation. The top level Document Package numbers for each transmitter
model are shown below:
• ULX-1100**, ULX-1700** ULX-2300**, ULX-3400**, ULX-4400**, ULX-
5500**, ULX-6500**, ULX-8700**: 988-2629-200
• ULX-9500**, ULX-12600**, ULX-17400**: 988-2629-201
• ULX-18900**, ULX-26100**: 988-2629-202
A Document Package includes:
1. This technical manual: 888-2629-200
2. Exciter manuals:
a. 888-2624-001 Common Sections
b. 888-2624-003 DVB-T/H Section
c. 888-2624-004 ISDB-T/H
d. 888-2624-006 FLO
e. 888-2624-007 CMMB
f. 888-2624-008 CTTB
3. Drawing Package with a complete set of schematics for the transmitter
system.
2.2.1 Installation Drawings
It is recommended that you look through the drawing package to familiarize yourself
with the information available. Although drawings are provided for most assemblies in
the transmitter, most of the installation and planning information is given in the
following drawings (see Table 2-2 below for model-specific numbers):
a. Outline Drawing - Shows connections for AC, control, coolant lines and RF out-
put. Also gives cabinet dimensions, required cabinet clearances and a table of
basic requirements for all models.
b. AC Power Flow Diagram - Shows overall AC wiring and has information on
proper wire, fuse and breaker sizes as well as location of disconnects.
c. RF System Layout - Shows a typical placement of the transmitter RF
components based on minimum required clearances.
d. Electrical Installation Diagram - Shows interconnect wiring between transmitter
and all external systems, including AC connections.
