WARNING: Disconnect primary power prior to servicing.
Section 2 Installation
Maxiva ULX COFDM Series
e. Wiring Diagram (Main Cabinet) and Wiring Diagram Additional PA Cabinet
(for multi-cabinet models) - Interconnection wiring diagram for all assemblies
inside the main transmitter cabinet or additional PA cabinets.
f. Intercabinet Wiring Diagram - Indicates the connections between multiple PA
cabinets, and jumper ID settings (for the multi-cabinet models).
g. Cooling System Outline - Shows specifications, dimensions and basic
requirements for the Pump Module and Heat Exchanger units.
h. Liquid Cooling System Layout - Shows basic plumbing component locations
and connections, flow rate and pressure information as well as simplified cooling
diagrams.
i. Cooling System Electrical Diagram - Shows the internal workings of the
Cooling Control Panel and all interconnects with transmitter, pump module and
heat exchanger, including AC connections.
Table 2-2 Maxiva ULX System Drawings
System Drawings
ULX-1100**
ULX-1700**
ULX-2300**
ULX-34700**
ULX-4400**
ULX-5500**
ULX65200**
ULX-8700**
ULX-9500**
ULX-12600**
ULX-17400**
ULX-18900**
ULX-26100**
Drawing Package 943-5601-511 943-5601-300 943-5601-308
Cover Sheet 843-5601-511 843-5601-300 843-5601-308
Outline Drawing 843-5601-279
Block Diagram 843-5601-284
AC Power Flow 843-5601-583 843-5601-597
RF System Layout 843-5601-281
Electrical Installation 843-5601-705
Wiring Diagram Main
Cabinet
843-5601-001
Layout, Plumbing 843-5601-281
