10/6/10 888-2629-200 2-63
WARNING: Disconnect primary power prior to servicing.
Section 2 Installation
Maxiva ULX COFDM Series
Table 2-15 External RF Switch J10
2.16 Install Battery in TCU PCM Card
When the transmitter is ready for operation install the real time clock battery in the
TCU PCM card. This battery maintains the time and date when the transmitter loses AC
power. Refer to "5.11.4 Changing the Battery on the PCM Card" on page 5-40. The
battery can be found inside a plastic bag that also contains battery installation
instructions.
Connection Metered Parameter
J9-1 SWITCH_COMMON
J9-2 GROUND
J9-3 RF_SWITCH_POSITION_A_SELECT
J9-4 RF_SWITCH_POSITION_B_SELECT
J9-5 GROUND
J9-6 RF_SWITCH_STATUS_A
J9-7 RF-SWITCH_STATUS_B
J9-8 GROUND
J9-9 GROUND
J9-10 NC
J9-11 NC
J9-12 NC
