Harris Maxiva ULX User Manual

10/6/10 888-2629-200 4-23
WARNING: Disconnect primary power prior to servicing.
Section 4 Theory of Operation
Maxiva ULX COFDM Series
PA Three Strike
Sequence
PA module three strike operation required operational
PCM.
YES
Manual Pump Switch
Over
Pump switch over controlled by push button from pump
control card or by parallel remote interface.
YES
Automatic Pump
Switch Over
Automatic switch over of pumps if in Auto. YES
Automatic
Transmitter Power
Control (ALC)
Transmitter power automatic level control if in AUTO. YES
VSWR Protection YES
Fold Back Operation YES
PA Module Summary
Fault Monitoring
YES
PA Module Deep
Fault Monitoring
YES
PA Module Meter
Readings
Not available due to loss of GUI display. NO
AC Faults
Monitoring
YES
Liquid Inlet/Outlet
Temperature Faults
YES
Flow and
Temperature Meter
Readings
Not available due to loss of GUI display. NO
Cabinet Summary
Fault
YES
Safety Interlocks YES
RF Mute Interlocks YES
Remote Metering Not available due to web loss but available on parallel
remote.
NO/YES
Basic Parallel
Remote Control
YES
Basic Parallel Status
Lines
YES
Table 4-10 Life Support Functionality
System Function Description Available in
Life Support
Mode
