10/6/10 888-2629-200 5-7
WARNING: Disconnect primary power prior to servicing.
Section 5 Maintenance and Alignments
Maxiva ULX COFDM Series
Figure 5-3 PA Module/Rack Alignment
STEP 5 Loosen hoses between upper and lower manifolds (If more than 8
PA's).
NOTE:
The system was drained to avoid leaking at this connection when the clamp is
loosened. Loosening the clamp allows the upper and lower manifolds to move
relative to each other.
Manifold Clamps
Upper
Manifold Clamps
Lower
Interconnect Hoses
Manifold
Drain Hoses
Cabinet
To Next Page
