10/6/10 888-2629-200 5-35
WARNING: Disconnect primary power prior to servicing.
Section 5 Maintenance and Alignments
Maxiva ULX COFDM Series
initial installation may vary depending on site conditions but in most cases annual
inspection and cleaning of the cooling system strainer is recommended. The strainer
must be disassembled and cleaned when the transmitter is off the air since the coolant
flow must be disrupted prior to opening the strainer assembly. Follow the steps that
follow to clean the strainer:
a. Turn off the transmitter and pump module.
b. Close the ball valves on either side of the strainer.
!
CAUTION:
WEAR SUITABLE PROTECTIVE GLOVES AND EYE PROTECTION WHEN
REMOVING THE STRAINER CAP. LOOSEN THE CAP SLOWLY SINCE THE
COOLANT MAY BE UNDER PRESSURE. THE COOLANT MAY ALSO BE HOT.
c. Remove strainer housing cap.
StrainerAssy.
Screen
Plug/Drain.
