WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Maxiva ULX COFDM Series
971 0040 031 "PRE DRIVER TRAY, MAXIVA ULX" 2 EA "A12A2,A12A3"
Table 7-16 "FORMAT, EXCITER, APEX M2X (DVB-T/H)" - 995 0063 001 (H 5)
Harris PN Description Qty UM Reference Designators
917 2501 156 "LABEL, LABEL CE" 1 EA
971 0035 003 "KIT, BATTERY BACKUP" 0 EA
9710035011G ASM-SUB-TX/IO INTERFACE MODULE 0 EA
981 0274 001 "EXCITER, APEX M2X BASIC" 1 EA
971 0035 014 ASM-SUB-BLANK PANEL B 1 EA
971 0035 015 ASM-SUB-BLANK PANEL C 0 EA
971 0035 013 ASM-SUB-BLANK PANEL A 1 EA
Table 7-17 "EXCITER, APEX M2X BASIC" - 981 0274 001 (Y 5)
Harris PN Description Qty UM Reference Designators
266010007 "GROMMET STRIP, 0.063" 0.15 FT
550100005 "*THERMAL COMPOUND, 8OZ JAR" 0 EA
860001002 "*ADHESIVE, THREADLOCK 242" 0 EA
860001004 "SEALANT, HIGH STRENGTH" 0 EA
252-808-000 "SCREW, FHMS M3-0.5 X 6 SST" 28 EA
256 0227 000 "CABLE, FFC 40C, 2ROW 61MM LONG" 3 EA "W3,W4,W5"
302 0803 006 "SCREW, MACH M3-0.5 X 6 SEMS" 13 EA
302 0804 008 "SCREW, MACH M4-0.7 X 8 SEMS" 8 EA
303 4104 016 "SCREW, MACH M4-0.7 X 16" 1 EA
303 4203 006 SCREW MACH M3-0.5 X 6 4 EA
303 4204 035 "SCREW, MACH M4-0.7 X 35" 4 EA
304 0174 000 "NUT, JAM, BRASS 1/2-28" 7 EA
306 0028 000 "NUT, HEX KEPS M4 ZINC" 10 EA
307 0001 040 "NUT, STD HEX M4-0.7 X .8H" 2 EA
314 0014 000 "WASHER, INT LOCK 1/2" 7 EA
315 0023 040 "WASHER, EXT LOCK M4" 3 EA
33-351 "EMI CLIP, SMALL SINGLE" 19 EA
336 1330 000 STDOFF-M/F-4.5MM HEX-M3X0.5X5L 13 EA
337 0005 000 "SCREW, SEMS M3 X 6 SKT HD, SST" 3 EA
35-733 "STUD,BALL,TREELOCK" 4 EA
356 0216 000 "CABLE TIE, 5.6'' NYLON NATURAL" 3 EA
358 1214 000 "SCREWLOCK, M/F 4-40X3/16""" 2 EA
410 0471 000 "STANDOFF, HEX M3 X 16, M/F" 6 EA
426 0149 000 VIBRATION MOUNT M/F .375D X .625H 4 EA
430 0325 000 "FAN GUARD, 80MM WIRE-FORM" 2 EA
430 0478 000 "FAN, RADIAL, 12V 46.62CFM 80MM" 2 EA
610 1425 003 "RECP, 3C 1ROW VERTICAL" 2 EA
646 0665 000 "LABEL, INSPECTION" 1 EA
646 2110 000 "BARCODE, SN_ITEM_REV" 1 EA
660 0093 000 "BATTERY, LITHIUM 3V 10MM COIN" 1 EA #BT1
843 5588 001 WIRING DIAGRAM UEP 0 DWG
843 5588 038 "FAMILY TREE, UEP" 0 DWG
9010213011G "*PWA, MCF5484 UC MODULE" 1 EA
9010215101G "*PWA, UP/DOWN CONVERTER" 1 EA
9010215181G "*PWA, SIGNAL PROCESSOR" 1 EA
943 5588 002 CHASSIS_M2X 1 EA
943 5588 020 "HEATSINK, AMPLIFIER MODULE" 1 EA
