10/6/10 888-2629-200 A-3
WARNING: Disconnect primary power prior to servicing.
Maxiva ULX COFDM Series
Figure A-2 Outer Conductor Measurements
Figure A-3 Measurement for Cutback of Inner Conductor
See Section Below
Cut Length
Outer Conductor
Flange to Flange Length
Flange
Silver Solder Ring
(some suppliers may
not provide this grove)
Outer Conductor
Cut Back For Each Flange
Groove For
O-ring
Mating Surface
Teflon Portion
of Bullet
Note: The cutback will vary for different
transmission line manufacturers.
Cutback
for inner
conductor.
The amount of cutback vary for different
transmission line manufacturers.
