HBM MX440B - Full bridge, inductive

Transducer connection
Quantum
X
I3031-14.0 HBM: public 139
9.2 Full bridge, inductive
Supported by the following modules: MX840B, MX440B,
MX410B
8
7
4
9
wh
bk
rd
bu
gn
gy
ye
1
2
4
3
Measurement signal (+)
Excitation (+)
Sense lead (-)
Sense lead (+)
Excitation (-)
Measurement signal (-)
Cable shield
10
Hsg.
2
3
5
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
Hsg. = Housing
1
5
6
10
11
15
6
1
123
1-wire EEPROM (optional)
view from below
2 Data
3 No function
1
