Modules and transducers
134 I3031-14.0 HBM: public Quantum
X
Important
MX1615B uses the "Mini Combicon AU“ socket/plug type
from Phoenix with gold pins for sensor connection,
instead of "Mini Combicon“ as used with MX1615.
It is essential to make sure that the right connector is
used:
MX1615B > 1CONS1015; MX1615 > 1CONS1005.
8.11.1 MX1615B pin assignment
So that insertion or removal of a transducer connection
can be unmistakably identified, Pin 4 and Pin 5 in the
connector plug must be bridged! This is automatically so
for all bridge transducers. The bridge only needs to be
completed for voltage measurements. If this bridge is
missing, no measurement values will be recorded at the
connection!
