Modules and transducers
128 I3031-14.0 HBM: public Quantum
X
MX1601B connectable transducers
Transducer type Connection sockets See page
Electrical voltage 1 ... 16 150, 151
Electrical current 1 ... 16 154
Current-fed piezoelectric transducer
(IEPE,
ICP®) via an external ad
apter
1 ... 16 148
8.10.1 MX1601B pin assignment
So that insertion or removal of a transducer connection
can be unmistakably identified, Pin 2 and Pin 5 in the
connector plug must be bridged! If this bridge is missing,
no measurement values will be recorded at the connec
tion!
