HBM MX440B - Half Bridge, Inductive

Transducer connection
142 I3031-14.0 HBM: public Quantum
X
9.5 Half bridge, inductive
Supported by the following modules: MX840B, MX440B,
MX410B
8
7
4
9
Hsg.
2
3
5
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
wh
bk
bu
gn
gy
ye
Measurement signal (+)
Excitation (+)
Sense lead (-)
Sense lead (+)
Excitation (-)
Cable shield
Hsg. = Housing
6
1
123
1
5
6
10
11
15
2 Data
3 No function
1
1-wire EEPROM (optional)
view from below
