Accessories

Quantum

I3031-14.0 HBM: public 211

12.1.3 Housing connection elements

Case clip

Covers for

housings with

protection class

IP65

12.2 Voltage supply

12.2.1 Power pack NTX001

Modules

NTX001

3 m

Mains

Europe mains cable

Australia mains cable

USA mains cable

UK mains cable

Order number: 1-NTX001
