Mechanical
42 I3031-14.0 HBM: public Quantum
X
cluded in scope of delivery). To do this, the existing lat
eral covers must be removed and the housing clips
screwed on.
6.1 Mounting case clips on modules
The module electronics are integrated in a metal housing
that is surrounded by a case protection (CASEPROT).
This also serves for centering when several devices are
stacked on top of each other and offers a certain degree
of protection against mechanical damage.
MX840 housing
Case protection
Cover
Fig. 6.1 Amplifier MX840 with case protection
The mounting of the housing clips shown in the following
pictures must be implemented on both sides of the hous
ing.
