Modules and transducers
Quantum
X
I3031-14.0 HBM: public 113
Flashing orange Download active, system is not ready
Red Error
Connection LEDs
All LEDs are orange Boot procedure running (system is not ready)
All LEDs are flashing
orange
Firmware download active (system is not ready)
Orange Connection newly assigned, transducer identification running
(calibration)
Green Error-free operation
Flashing green (5s),
then green
TEDS data being read in
Flashing orange (5 s),
then green
Manual configuration ongoing (ignore TEDS)
Red No sensor connected
Channel error (incorrectly parameterized, connection error,
invalid TEDS data)
CAN LEDs
Green CAN bus activated, CAN data can be received
Orange CAN bus in "WARNING" state, CAN data received but bus is
subject to occasional disruptions; buffer overflow, some data
items lost
Red CAN bus in "ERROR" or "BUS-OFF" state, CAN data cannot
be received or processed
General rule: Brief flashing TEDS identified (green: is used,
orange: is not used).
8.7 MX460B frequency amplifier
You can connect up to four transducers to the frequency
measuring amplifier MX460B. The transducers are con
nected via 15-pin D-SUB-15HD device connectors. All
