12.2.2 Supply cable

3m 30

Approx. 10-15

Twisted and tinned

Cable LIYY 2x0.5 mm

Plug ODU Medi‐Snap

S11M08-P04MJGO-5280

0 V

Supply voltage

black

brown

Order number: 1-Kab271-3 (length 3 m)
