HBM MX440B - Passive Inductive Encoder (Pickups, Crankshaft Sensor)

Transducer connection
Quantum
X
I3031-14.0 HBM: public 169
9.28 Passive inductive encoder (Pickups,
Crankshaft sensor)
Supported by the MX460B module.
9
4
Hsg.
14
Ground
Cable shield
f
1
AC+
6
1
5
6
10
11
15
Gap
6
1
1
2
3
2 Data
1
Maximum input voltage to housing and supply
ground: "60 V
Crankshaft sensor / OT sensor
Example for a crankshaft wheel with gap
3 No function
1-wire EEPROM (optional)
view from below
Hsg. = Housing
