Transducer connection
168 I3031-14.0 HBM: public Quantum
X
9
4
Hsg.
10
7
f
1
(-)
Ground
SSI
Cable shield
f
1
(+)
f
2
(-)
f
2
(+)
8
6
5
f
1 (-)
= Data (-)
f
1 (+)
= Data (+)
f
2 (-)
= Shift clock (-)
f
2 (+)
= Shift clock (+)
Hsg. = Housing
1
5
6
10
11
15
Adjustable sensor supply: Pin12: 5 V ... 24 V
Pin 11: 0 V
