Modules and transducers
122 I3031-14.0 HBM: public Quantum
X
Red No sensor connected
Channel error (incorrectly parameterized, connection er
ror, invalid TEDS data)
Red Sensor supply overload
General rule: Brief flashing TEDS identified (green: is used,
orange: is not used).
8.9 MX471B CAN module
8.9.1 General information
The MX471B module provides four independent CAN
bus nodes that are all electrically isolated from each
other and power supply.
Connectable MX471B buses
Type
Connector sockets /
nodes
See
page
CAN bus (high‐speed CAN) 1 ... 4 173
Connected devices are not directly addressed during
data transmission on a CAN bus. A unique identifier de
notes the contents of a message (e.g. rotational speed or
engine temperature).
The identifier also signifies the priority of the message.
Message = identifier + signal + additional information
Device connected to the bus = node
