Modules and transducers
Quantum
X
I3031-14.0 HBM: public 123
Each node on the MX471 can be parameterized either as
a receiver or as transmitter (gateway). Parameterization
as receiver is described in section 8.9.4. Parameteriza
tion as transmitter is described in section 9. The online
help that comes with the respective software package
provides detailed information about parameterization.
Notice
To ensure normal operation, the CAN bus needs to be
terminated at both ends, and only there, using appropri
ate termination resistors.
A 120-ohm termination resistor can be individually con
nected in the module by software. Termination is also
required when short cables with low bit rates are used.
Please refer to the data sheet for the relation between bit
rate and maximum bus line length.
The configuration of a node is retained after switching the
modules off and on.
For decoding signals at a rate greater than 2000/s,
please set up signal inputs 1 to 8 on the MX471. The sig
nal buffers of these signal inputs have been expanded
accordingly.
