HBM MX440B - DC voltage sources 10 V

Transducer connection
Quantum
X
I3031-14.0 HBM: public 151
9.13 DC voltage sources 10 V
The following amplifiers support a measuring range of
"10 V: MX410B, MX840B, MX440B, MX1601B
Pin assignments for MX1601B see section 8.10.1
Pin assignment for module MX1615B see section 8.11.1
9
4
Hsg.
14
(-)
(+)
U
Cable shield
Hsg. = Housing
6
1
12 3
1-wire EEPROM (optional)
view from below
1
5
6
10
11
15
2 Data
3 No function
1
MX1615B
6
4
5
7
8
1
1
5
2
8
4
MX1601B
Maximum input voltage to housing and
supply ground:
MX840B, MX440B, MX1601B: "60 V
MX1615B: "15 V
MX1601: "15 V
Sensor supply: 5 V … 24 V:
0 V:
Pin 12
Pin 11
Pin 6
Pin 7
1
8
Push in
1
8
Push in
MX1601B: Only channels 1-8 offer an individual sensor
supply of 5-24 V
Channels 9-16 can be activated with a fixed sensor sup
ply (-1 V module supply voltage).
