HBM MX440B - Page 149

Transducer connection
Quantum
X
I3031-14.0 HBM: public 149
14
Hsg.
9(-)
(+)
4
Cable shield
IEPE
BNC adapter option
(1-SUBHD15-BNC)
Hsg. = Housing
1
5
6
10
11
15
MX1601B
5
2
1
8
1
8
Push in
Notice
IEPE transducers with TEDS version 1.0 are supported.
