Accessories
202 I3031-14.0 HBM: public Quantum
X
Transducer side
General information
Article Description Order no.
D-Sub-HD 15‐pin plug
set with TEDS chip
Plug kit D-Sub HD 15-pin (male) with TEDS
chip DS24B33f. Housing: metallized plastic
with knurled screws.
Note: the TEDS chip is blank.
1-SUBHD15-
MALE
D-Sub-HD 15‐pin port
saver
Four fully wired port savers protect
D-Sub-HD 15-pin ports against wear and
tear due to frequent plugging and unplug
ging of transducers. Extends durability by at
least 500 contact cycles.
Construction: plug in socket with screw con
nection.
1-SUBHD15-
SAVE
DSubHD 15‐pin
300 V CAT II adapter
Voltage signal conditioner 300 V (CAT II),
TEDS, D‐SUB-HD device connection, insu
lated lab measuring lead (length 0.5 m).
1-SCM-HV
DSubHD 15‐pin SG
quarter bridge ad
apter
SG quarter bridge adapter (SCMSG120
with 120 ohm completion resistor, or
SCMSG350 with 350 ohm completion
resistor).
Signal conditioning SG quarter bridge on
QuantumX input with full bridge. Integrated
120-ohm (350-ohm) completion resistor for
quarter bridge, shunt calibration, TEDS,
D-Sub-HD device connection, Solder joints
for transducer lead in a 3wire configuration.
1-SCM-SG120
1-SCM-SG350
DSubHD 15‐pin to
adapter BNC
BNCsockettoDSubHD15pinplug adap
ter for connection of currentfed, piezoelec
tric sensors (IEPE) or voltage ("10 V) with
BNC to MX410B, MX840B or MX440B
(length approx. 5 cm).
1-SUBHD15-
BNC
