Connecting individual QuantumX modules
60 I3031-14.0 HBM: public Quantum
X
Typical power consumption, including
transducer excitation (watts)
Module
MX471B 6
MX1601B 13
MX1615B 12
MX1609/KB/TB 6
MX809B 6
CX22B-W/
CX22B
12
CX27B 7
MX878B 7
MX879B 7
If several modules are connected to each other via
FireWire for time-synchronous data acquisition (see
Fig. 7.4), the supply voltage can be looped through. The
power pack used must be able to provide the appropriate
output.
The maximum permissible current on the IEEE1394b
FireWire connection cable is 1.5 A. If the chain is longer,
repeating the supply connection is mandatory.
If several amplifiers are operated non-synchronously (see
Fig. 7.3), they must be supplied separately.
