Connecting individual QuantumX modules
68 I3031-14.0 HBM: public Quantum
X
Example:
Setting the IP address manually – module side
Settings IP address Subnet mask
Module before 169.1.1.22 255.255.255.0
PC / notebook 172.21.108.51 255.255.248.0
Module after 172.21.108.1 255.255.248.0
The first three digit groups of the PC and module IP
addresses should be the same.
The subnet mask address digit groups must be identical
in the module and PC!
