Connecting individual QuantumX modules

86 I3031-14.0 HBM: public Quantum

10 V ... 30 V DC

Optohub

Fiber optical cable

Max. length 300 m

Fig. 7.16 FireWire 1394b optohubs and fiber optical cable

from HBM partner Allied Vision Technologies
