Command reference Menu 3. SETUP
EN 3925-0060 V207-00 MANUAL R03.doc
HeMaTech Prüftechnik
61
Continued
… Test
pressure;
Measuring
time;
Volume factor;
Rework;
Leak
Leak with 6 digits
Rework with 6 digits
Volume factor with 9 or 6 digits
Measuring time with 6 digits
Test pressure with 6 digits
In addition to the measuring data in format Datei01 format Datei02 will also provide
the following data:
Test pressure:
Specifies the test pressure for the test with 6 digit. The output width is always 6 digits.
The unit for the test pressure is bar/ü.
Measuring time:
Shows the entered measuring time in a structured representation. The unit for the
measuring time is seconds.
Volume multiplier:
Shows the volume multiplier, used to calculate the measuring values, in a structured
representation. The output width is always 9 or 6 digits.
Rework:
Specifies the limit contact for rework in the adapted structured representation. The
output width is always 6 digits.
Reject:
Specifies the limit contact for leak in the adapted structured representation. The output
width is always 6 digits.
Examples for the output of measuring data in the format File02.
Accept
00000001;01;24022002;152621;000000;01;01;00;1,00:3,00;1,0000000;50;100
Gross leak (major leak)
00000002;01;24022002;152637;------;01;04;00;1,00:3,00;1,0000000;50;100
Error
00000003;01;24022002;152718;------;01; --;25;1,00:3,00;1,0000000;50;100
