Command reference Menu 3. SETUP
EN 3925-0060 V207-00 MANUAL R03.doc
HeMaTech Prüftechnik
63
The Profibus inputs and outputs
If the Profibus is activated, it will take over the following inputs/outputs:
Description
Type
Byte/Bit
3925-0050 LEAK
3925-0150
FLOW
3925-0350
VOLUME
Input
1.0
Internal reserved
Input
1.1
Internal reserved
Input
1.2
Internal reserved
Input
1.3
Internal reserved
Input
1.4
Internal reserved
Input
1.5
Internal reserved
Input
1.6
Internal reserved
Input
1.7
Internal reserved
Input
2 . 0
Machine ready
Input
2 . 1
Start
Input
2 . 2
Leak simulation
Reserve
Reserve
Input
2 . 3
Static test (Flooding)
Reserve
Input
2 . 4
Abort
Input
2 . 5
Automatic
Input
2 . 6
Reserve
Input
2 . 7
Reserve
Input
3 .0
BCD 01 (Program selection)
Input
3 . 1
BCD 02 (Program selection)
Input
3 . 2
BCD 04 (Program selection)
Input
3 . 3
BCD 08 (Program selection)
Input
3 . 4
BCD 10 (Program selection)
Input
3 . 5
BCD 20 (Program selection)
Input
3 . 6
BCD 40 (Program selection)
Input
3 . 7
BCD 80 (Program selection)
Input
4.0
External reserve
Input
4.1
External reserve
Input
4.2
External reserve
Input
4.3
External reserve
Input
4.4
External reserve
Input
4.5
External reserve
Input
4.6
External reserve
Input
4.7
External reserve
