Description
Type
Byte/Bit
3925-0050 LEAK
3925-0150
FLOW
3925-0350
VOLUME
Output
7 . 0 ... 7
Measuring value identifier
Output
8 . 0 ... 7
1. Digit measuring value
Output
9 . 0 ... 7
2. Digit measuring value
Output
10 . 0 ... 7
3. Digit measuring value
Output
11 . 0 ... 7
4. Digit measuring value
Output
12 . 0 ... 7
5. Digit measuring value
Output
13 . 0 ... 7
6. Digit measuring value
Output
14 . 0 ... 7
7. Digit measuring value
Output
15 – 0 ... 7
7. Digit measuring value
Output
16 . 0 ... 7
9. Digit measuring value
Output
17 . 0 ... 7
10. Digit measuring value
Output
18 . 0 ... 7
11. Digit measuring value
Output
19 .0 ... 7
12. Digit measuring value
Output
20 . 0 ... 7
13. Digit measuring value
Output
21 . 0 ... 7
14. Digit measuring value
Output
22 . 0 ... 7
15. Digit measuring value
Output
23 . 0 ... 7
16. Digit measuring value
The following identifier are possible:
ASCII „0“ = Measuring value invalid
ASCII „1“ = Measuring value in measuring range 1
ASCII „2“ = Measuring value in Measuring range 2
ASCII „3“ = Measuring value in Measuring range 3
ASCII „4“ = Measuring value in Measuring range 4
ASCII „5“ = Measuring value in Measuring range 5
ASCII „6“ = Measuring value in Measuring range 6
ASCII „G“ = Gross leak
ASCII „H“ = Envelop curve leaving
ASCII „F“ = Error
The measuring value occupies 17 output bytes on the Profibus starting from the 7
th
output byte. All data outputs take place in the ASCII format.
For devices with Profibus you require the file PLC07v100.GSD for configuring the Pro-
fibus Master, this file is delivered on a separate CD.
